Product Detail
| Product Detail Info: | |
| Voltage | AC 200V~240V, 50～60Hz |
| Power Consumption | 2500W |
| Lamp | XQ 2KW |
| Lamp Life | 1000 hours (Luminance degradation begins after 600 hours of operation) |
| IP Rating | IP44 |
| Features a specially designed reflector for maximum luminance output. | |
| Pan Movement (X-Axis) | |
| Range | 540°, equipped with photosensitive error correction for automatic homing calibration. |
| Fine Adjustment | 5.4° micro-adjustment for more precise positioning. |
| Tilt Movement (Y-Axis) | |
| Range | 270°, equipped with photosensitive error correction for automatic homing calibration. |
| Fine Adjustment | 5.4° micro-adjustment for more precise positioning. |
| Color System | |
| White light + CMY color mixing system, capable of creating a wide variety of colors. | |
| Optical Performance | |
| Parallel beam output with a projection distance of up to 2 km. | |
| Beam diameter | 250 mm. |
| Protection Features | |
| Built-in protection against overvoltage, overheating, overload, and short circuits. | |
| Dimensions | |
| Unit Dimensions | 500 × 420 × 730 mm |
| Packaging Dimensions | 570 × 470 × 840 mm |
| Control & Programming | |
| Control Signal | DMX-512 |
| Built-in programs for standalone operation (single unit). | |
| Master/slave synchronization for multi-unit operation. | |
| Control signal reset function. | |
| Reverse function for both X-axis and Y-axis movement | |
