Input voltage / frequency

AC100V-240V, 50/60Hz.

Rated power

450W/650W

Light source

use 330W/350W/380W Osram or Philips bulb or yodn bulb

Beam angle

3.8 ° -45 °, zoom lens, linear zoom

Control channel

16/22 standard DMX channels.

Operating mode

voice control, self-propelled, master-slave, DMX512

Pattern, beam, and wash 3in1 function

Color wheel

 13 colors + white light, linear color conversion and rainbow effect

2 gobo wheels

fixed gobo wheel: 14gobos + white color, rotating gobo wheel: 9 gobos + white light.

Prismatic mirror

two independent prism discs, one 8 prism, one 3D effect 6 prism, (8, 16, 24 prisms can be selected), prism and prism front and back free rotation function, prism positioning function.

Focusing

DMX linear high-definition focusing, 2 meters to infinity sharpness adjustment, the far and near definition of the gobo can be adjusted freely.

Atomization

It can produce soft effect adjustment, 0%~100% linear atomization.

Strobe

Double-chip high-speed strobe, 1-15 times / sec.

Dimming

0-100% mechanical linear dimming.

Horizontal/Vertical

Horizontal scanning angle 540°, vertical scanning angle 270°, 8 or 16Bit precision fine adjustment, automatic return and correction function; fast speed, smooth running without flick, low noise, accurate positioning.

Display interface

LCD liquid crystal display interface, can switch between Chinese and English display.

Lamp housing

high temperature engineering plastics and alloy materials, streamlined design, beautiful appearance.

Protection level

IP20

RDM function

makes it easier for dmx address setting through the controller
